Elektra Sense
Elektra Sense is a next-generation compact AC wallbox designed for flexible and efficient EV charging. Developed with the needs of EV charging service providers in mind, it offers a smart balance of performance, simplicity and adaptability for a rapidly evolving charging landscape.
Its compact footprint makes Elektra Sense a natural fit for space-limited sites, while quick installation keeps rollouts smooth and predictable. Smart features support easy configuration and ongoing management, helping operators scale from single locations to larger networks without adding complexity.
Feel free to ask from our specialist:
Prefer we contact you instead?
Share your details and our team will reach out with the information you need.
Effortless Installation
Scalable Performance
Reliable Connectivity
Technical Features:
Charging category
AC charging mode 3
Charging interface
Type 2 socket, optional Schuko socket
Output
2 * 22 kW / 32A
Voltage
230/400 V AC, 50 Hz
Input connection
Cu/Al 2x16 mm2, daisy chaining
Residual current protection
30 mA AC RCBO + 6 mA DC RCD
Load balancing
Local DLM, cloud DLM
Energy metering
MID-certified energy metering
ISO15118
Plug & Charge + V2G ready
Connectivity
4G LTE, WLAN, ETH LAN
Communication protocol
OCPP 1.6 J, Modbus TCP/RTU
IP / IK class
IP54 / IK10
